Micro Channel Aluminium flat tube
The microchannel aluminium flat tube is a high-tech product project created by Runfa Aluminium after two years of hard work. This project adopts the most advanced production, processing and testing equipment and is equipped with a mature elite team from R&D, production to sales services. It has an annual production capacity of 10,000 tons, various types of microchannel aluminium flat tubes, wide MPE and special profiles,etc. Mainly used in heat exchange and refrigeration fields such as automobiles, home & commercial air conditioners, refrigerators, batteries and 5G. This project will adhere to Runfa's precision management principle of aluminum foil products to ensure excellence and continuous improvement in all aspects such as technology, management, quality, cost and service.
Section Drawing Images:
Main Size:
Width | Thickness | Wall Thickness | Length |
10-125MM | 1.0-8.0MM | 0.2-0.8MM | 150-8000MM |
Alloy & Chemical Composition:
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | V | Ti |
1050 | ≤0.25 | ≤0.40 | ≤0.05 | ≤0.05 | ≤0.05 | — | ≤0.05 | — | ≤0.03 |
1100 | ≤0.95 Si+Fe | 0.05~0.20 | ≤0.05 | — | — | ≤0.10 | — | ≤0.05 | |
1197 | ≤0.15 | ≤0.20 | 0.40~0.55 | 0.10~0.30 | ≤0.03 | — | ≤0.05 | — | ≤0.05 |
3102 | ≤0.40 | ≤0.70 | ≤0.10 | 0.05~0.40 | — | — | ≤0.30 | — | ≤0.05 |
3F03 | ≤0.15 | ≤0.20 | ≤0.05 | 0.90~1.10 | ≤0.03 | — | ≤0.05 | — | ≤0.05 |
3003 | ≤0.60 | ≤0.70 | 0.05~~0.20 | 1.0~1.5 | — | — | ≤0.10 | — | — |
Mechanical Property:
Alloy | Temper | Tensile Strength Rm MPa | Yield Strength Rp0.2 Mpa | Elongation（%） |
1050 | H112 | ≥60 | ≥20 | ≥25 |
3102/1100/1197 | H112 | ≥75 | ≥25 | ≥25 |
3F03 | H112 | ≥80 | ≥30 | ≥20 |
3003 | H112 | ≥95 | ≥35 | ≥25 |
